Description Machine Parts Winding machine parts Traverse motor Yarn guide motor Programmable tension tester Angular transducer Yarn break sensor Wire break alarm Motor photoelectric encoder Encoder disc Button switch Motor steel wire wheel / driven wheel The head of yarn guide, yarn guide wire rope Steel wire Traverse guide assembly 212 yarn guide cylinder 212 hand shank Winding motor Cone holder / adaptor Electronic gate tension Twister machine parts Tension capsule tensioner Spindle lining device Spindle wing tension device Terminal plate Overfeed roller Friction wheel Guide roller Brake Double-side synchronous belt Yarn connecting cable Automatic winding machine parts 522 machine part – electromagnetic clamp tensioner 522 electronic yarn guide cylinder (large and small) Inserting hook Tube fix device Electromagnetic valve Electromagnet seat Yarn cutter Tube shelf air cylinder Winding Machine Control System High-speed electronic yarn guide forming control system Forming length and slide angle are adjustable; cylindrical or cone winding can be chosen Yarn guide forming route is selectable; ensures the soft edge shape and controls uniform density Line speed can reach maximum 2200 m/min High-performance, high rotation speed stepper motor When running, the high revolution makes the yarn guide head a high-speed back and forth yarn guide forming Programmable digital tension sensors of yarn Overfeeding: makes the yarn feeding speed can be set up to keep pace with the constant overfeed ratio in winding According to the tension data, the yarn which in active tracking rotation can keep constant tension Thread guide mechanism apparatus Automatic Tracking and Initiative Unwinding Control System Developed for yarn that becomes more bulky after dyeing, causing yarn layers to touch and hinder unwinding Makes the bobbin of the soft skein unwind actively during rewinding process Unwinding speed can be controlled by the tension sensor Advantages: constant winding tension, improved winding speed, uniform yarn winding forming density, better unwinding performance at next process, decreased yarn broken faults According to the yarn tension sensor data, the yarn in the unwinding device has active tracking to get constant tension winding Auto-tracking initiative unwinding device can initiative unwind skein and cheese yarn Matches with all winding machines Yarn guide forming control system for two-for-one twisting machine Winding Machine Control System (Machine Parts) Winding machine control system machine parts Intelligent Refueling Box Uses stepping motor driven gear pump for intelligent control of oil supply Equipped with digital constant temperature control for high consistency of oil heating melting Alarms and stops automatically on oil failure or shortage Power supply voltage: 24V ± 2V Current consumption: off state 1 W, holding state 2 W, oiling state 5 W, heat the standby 15 W, heat the oil 30 W Operating environment: environment temperature from 10 to 40 °C, relative humidity from 0 to 80% Oil supply: from 0 to 40 g/min (small deviation between quantitative and actual quantity based on oil viscosity) Oil temperature: from 20 to 99 °C (temperature difference ± 2 °C) Constant Tension Feeder Device for precise measuring / feeding and yarn tension control Constant tension ensures smooth cloth and long wide line Fast changing yarn does not produce tim yarn defect Operating is simple, sensor is automatic zero Motor power is strong, sensitive reaction Pre-designed length and target length down Measuring length of sand, accuracy can reach 0.1 mm Yarn left preparation area automatically sends a certain length to ensure yarn from the yarn clamp Power voltage: 24V/36V Maximum power: 3A Maximum power consume: 35 VA Maximum linear velocity: 1500 m/min Range tension: 0.5 to 90 g Maximum return length: 600 mm Weight: 0.7 kg Programmable Tension Sensor Accurate detection to the yarn tension Power supply voltage: 12-24 VDC +/- 10% Power supply correct: 80 mV Analogic output: 500 mV to 10 V Analogic output resistance: 1 k ohm Relative humidity: <93% Operating temperature: 0°C to 50°C Storage temperature: -25°C to 85°C Range tension: 0.5 to 90 g Range tension applicable: 0% to 95% end scale Drift error: ≤0.05% / °C Linearity error: 2% (0 to end scale)
