Applicable for multi-weight sorting of poultry, marine as well as agricultural products, such as chicken legs/wings/meat, trepang, abalone, small fish, shrimp, medical herbs, fruits and many other products with the size within 120 x 180 mm and the weight within 500 g (1–14 grade sorting), regardless of their shape.
Specifications
Maximum weighing: 500 g
Sorting accuracy: ±0.3 g
Sorting speed: 300 bpm
HMI: 7” color touch screen
Product size: ≤180 mm (L) x 120 mm (W)
Control system: high-speed A/D controller
PE-set prod. no.: 99
Power supply: AC220V±10% 50Hz/60Hz, 0.6 kW
Machine dimension: 3592 mm (L) x 1174 mm (W) x 1508 mm (H)
Reject device: overturned device
Sorting grades: 1 to 14 grades
Working Condition
Temperature: 0°C–40°C, humidity: 30%–95%
