Description Overview Multi-needle quilting machine with all functions of multi-needle quilting, plus single needle quilting capability. Higher output than single needle quilting machines and more patterns than multi-needle quilting machines. Chain stitch design avoids frequently replacing bottom thread. Needle bar and press plate controlled by a double-swinging device without cam, avoiding lubrication and dirtying of the fabric. Automatic stop motion control for top thread and bottom thread breaks. Ce certificate. No need to adjust press plate position when thickness of quilting material varies. Pattern-combining and tack & jump quilting to enable quilting different patterns in same mattress panel. Fault detection monitoring for ease of determining the running state of the machine at any given time. Gap between press plate and needle plate with a roller to pull material; works for 80 mm or 10 mm thickness without needing to adjust the pattern. Specifications Floor space dimension l x w x h: 4820 x 1650 x 2060 mm Quilting width: 2450 mm Space between needle rows: 1 x 3 x 6 Space between needles: 25.4 mm (one inch) X-axis movement displacement: 535 mm (21 inches) Thickness of quilting ≤ 60 mm (for all patterns) (2.3 inches) Stitch length: 3 to 8 mm Speed of operation: up to 230 meters/hour Needle type: 24/180; 23/160; 22/140; 21/130 Quilting speed: up to 980 rpm Total power required: 7 kW Voltage: 380 V / 50 Hz or 220 V / 60 Hz Gross weight: 5500 kg Shipping Requires one 40 foot hq container to ship the quilter and panel cutter.
