High quality "melt on demand" basic hot melt tanks used to melt and pump a range of hot melt adhesives at precise temperatures, flow rates and pressures through flexible hot melt hoses to hot melt handguns or automatic hot melt guns.
System: N05
Hopper capacity: 10 lbs (5 kg)
Operating temperature: 100 to 425°F (40 to 218°C)
Melt rate (per hour): 17.3 lb/hr (8 kg/hr) ** depends on hot melt
Pump rate (per hour): 2 lb/min (0.91 kg/min)
Gear pump: 1.5, 3.2, 4.5 and 10 cc
Hose output zones: 2
Temperature control stability: ± 1°F (1°C)
Electrical service standard: 100 to 120 vac 1 phase 50/60 Hz or 240 v
Working viscosity: 500 - 50,000 cps
Dimensions
Height: 17.75 in (45 cm)
Depth: 21.25 in (54 cm)
Width: 11.38 in (29 cm)
Weight (empty): 60 lbs (27 kg)
Features
10 lb capacity melt on demand tank with 10-12 lb per hour melt rate
Operates with up to two hoses and guns
Precision temperature controls with zone readout
Constant speed gear pumps
240 vac - no compressed air required
Options
Motor enable switch to turn on pump from dynachamp handgun
Specifications
Dimensions: 290x540x450mm
