Description Overview Integrated needle and self-cleaning nozzle virtually eliminate adhesive stringing (micro optima module). Dual-port pivoting modules simplify set-up by providing simple adjustment of bead placement. Adjustable needle stroke sets adhesive flow for extreme accuracy (micro adjustable module). On/off cycle speeds of 3.5 milliseconds is ideal for high-speed applications. Cover increases safety and promotes energy efficiency. Industry exclusive built-in filter captures debris and minimizes nozzle clogging. Compact size provides for easy installation into packaging machinery. Insulated thermoplastic cover increases safety by reducing operator exposure to hot surfaces. Enhanced built-in filter captures debris and reduces downtime due to clogged nozzles. Specifications Construction material: anodized aluminum/stainless steel. Operating temperature range: 38° C - 218° C (100° F - 425° F). Max on/off cycle speed (single port): 3.5 ms. Max on/off cycle speed (dual port): 4.0 ms. Max on/off cycle speed (dual port independent): 3.5 ms. Max adhesive pressure: 68 bar (1000 psi). Air pressure range: 4.8 - 9.5 bar (70-140 psi). Adhesive viscosity range: 100 - 5,000 cps. Filter mesh options: 100, 150, 200.
