NovaStar, BT124, Diesel Oil Fired Steam Boiler, 1.5 T/H, 1.0 MPa (New)

NovaStar, BT124, Diesel Oil Fired Steam Boiler, 1.5 T/H, 1.0 MPa

Description

  1. Overview
    1. Model: BT124
    2. Type: Horizontal
    3. Fuel: Diesel oil
    4. Rated evaporation: 1.5 t/h
    5. Rated working pressure: 1.0 MPa
    6. Rated steam temperature: 184 °C
  2. Boiler Technical Details
    1. Rated steam capacity: 1.5 ton/h
    2. Rated steam pressure: 1.0 MPa
    3. Hydraulic test pressure: 1.4 MPa
    4. Feed water temperature: 20 °C
    5. Rated steam temperature: 184 °C
    6. Heating efficiency: 98.8%
    7. Water capacity: 5.1 m³
    8. Available fuel: Diesel oil
    9. Fuel consumption: 95 kg/h
    10. Exhaust gas temperature: 75.6 °C
    11. Regulation method: Automatic
    12. Approximate dimension (L×W×H): 4294×1900×2214 mm
    13. Transportation max weight: 8 t
    14. Motor voltage: 380 V, 50 Hz (can be changed as requests)
  3. Boiler Accessories
    1. Diesel oil burner, model BT 180 DSPG, 1 set
    2. Electric cabinet, brand Rentai, 1 set
    3. Feed water pump, model JGGC3-8×22, N=4 kW, 2 sets
    4. Automatic water treatment softener, model FLEX-1.5, 1 set
    5. Sub-cylinder, diameter Φ219, 1 set
    6. Condenser, model LNQ-1.5T, 1 set
    7. Steel chimney, Φ350 × 8000, 1 unit
    8. Sampler, model TG-1.5, 1 set
  4. Technical Documents
    1. General drawing, 1 pc, Taiguo
    2. Boiler body drawing, 1 pc, Taiguo
    3. P&I drawing, 1 pc, Taiguo
    4. Foundation drawing, 1 pc, Taiguo
    5. Product quality certificate, 1 pc, Taiguo
    6. Installation operation manual, 1 pc, Taiguo
    7. Copy of manufacturer license, 1 pc, Taiguo
