Triveni, 25MW, 2019, Condensing Steam Turbine-Generator Package, 66 Bar, 11 kV, 50 Hz (New)

Triveni, 25MW, 2019, Condensing Steam Turbine-Generator Package, 66 Bar, 11 kV, 50 Hz

Description

  1. Overview
    1. Steam turbine, gearbox and generator package
    2. Year of manufacture: 2019
    3. Condition: new
    4. Operating hours: 0 – never installed
    5. Status: in storage
    6. Partially complete package, including all auxiliary equipment
    7. Designed for use with acc (acc is excluded)
  2. Steam Turbine
    1. Manufacturer: Triveni (India)
    2. Year of manufacture: 2019
    3. Type: condensing
    4. Rated power: 25000 kW
    5. Rated inlet steam pressure: 66 bar
    6. Rated inlet steam temperature: 425 deg c
    7. Speed: 6,141 rpm
  3. Gearbox
    1. Manufacturer: Lufkin
    2. Input speed: 6,141 rpm
    3. Output speed: 1,500 rpm
  4. Generator
    1. Manufacturer: Weg (India)
    2. Rated output: 31250 kva
    3. Power factor: 0.8
    4. Speed: 1,500 rpm
    5. Voltage: 11 kV
    6. Frequency: 50 Hz
