NovaStar, SR301, Slitting Width 650mm to 1010mm, Speed 400m/min, Siemens PLC (New)

NovaStar, SR301, Slitting Width 650mm to 1010mm, Speed 400m/min, Siemens PLC

Description

  1. Functional Description
    1. 30 pcs magnetic clip blade holders, change of blade is quick and easy.
    2. 4 pcs 1 inch air shafts and 4 pcs 1/2 inch air shafts, makes core loading easier. With the shafts holder, the rewinding shaft is very stable.
    3. Automatic tension control system, providing perfect slitting quality roll.
    4. Siemens plc control.
    5. 4 servo motors, sanyo japan inverter, for proper tension control.
    6. Siemens clear and easy control touch screen.
    7. Semi-automatic leader trailer station with ribbon saving function.
  2. Standard Accessories
    1. Main drive servo motor, sanyo, japan, 1 set
    2. Main drive motor converter, sanyo, japan, 1 set
    3. Rewinding servo motor, sanyo, japan, 2 sets
    4. Rewinding converter, sanyo, japan, 2 sets
    5. Unwinding servo motor, sanyo, japan, 1 set
    6. Unwinding converter, sanyo, japan, 1 set
    7. Plc unit, siemens, germany, 1 set
    8. Pneumatic components, airtac, taiwan, several
    9. Magnetic clip blade holder, 30 pcs
    10. Waste edge re-winder, 2 pcs
    11. 1 inch air shaft, 4 pcs
    12. 1/2 inch air shaft, 4 pcs
    13. Unwinding 6 inch shaftless, 1 set
    14. High speed precision bearing, nsk, japan, several
    15. Touch screen, siemens, germany, 1 set
    16. Meter counter, 1 set
    17. Machine frame color as per customer requirement, 1 set
    18. Operation manual, 1 set
  3. Spare Parts List
    1. Air gun, 1 pc
    2. Air nozzle, 4 pc
    3. Air shaft roll, 1/2 inch, 5 m
    4. Air shaft roll, 1 inch, 5 m
    5. Belt, 3 pcs
    6. Pedal switch, 1 pc
    7. Intermediate relay, 2 pcs
    8. Foam stripe, 1 roll
    9. Dustproof plate, 1 pc
    10. 1/2” inflatable pcs, 4 pcs
    11. 1” inflatable pcs, 4 pcs
  4. Leader and Trailer Feeding
    1. Leader film width: trailer 250 mm + medium 160 mm + leader 250 mm (width can be adjusted according to roll length, total width less than 830 mm).
    2. Film roll core inner diameter 3 inch, max diameter 300 mm.
  5. Adhesive Tape
    1. Max width 35 to 45 mm, core inner diameter 3 inch, max diameter 130 mm.
  6. Packing Details
    1. Packing size 220 x 160 x 120 mm, n.w. 1300 kgs, g.w. 1400 kgs
    2. Packing size 200 x 165 x 145 mm, n.w. 200 kgs, g.w. 280 kgs
  7. Specifications
    1. Capacity: Speed max 400m/min
    2. Weight: 2000
    3. Dimensions: 2760x2050x1760mm
    4. Slitting width: 650mm to 1010mm
    5. Unwind diameter: 600mm max
    6. Rewinding diameter: 140mm max
    7. Slitting thickness: 4 to 20 micron
