Description Overview Rapid plastimeter is a microprocessor-controlled unit with plasticity retention determination feature. Equipped with an ageing oven for precise ageing of elastomers. Host fast compression cylindrical specimens ensure rapid plasticity index determination. Variable loading duration provides compatible time adjustments of retention index testing. Used for determining the viscosity, plasticity, plastic retention index of unvulcanised and unprocessed natural rubber. Specifications Control temperature (main unit): 100 °C ± 0.5 °C Load: 100 N ± 1 N Upper plate dimensions: Φ 7.5 mm ± 0.02 mm, Φ 10 mm ± 0.02 mm, Φ 14 mm ± 0.02 mm Lower plate dimensions: Φ 16 mm Control temperature (ageing oven): 140 °C ± 0.2 °C Time: 30 min ± 5 sec Power supply: AC 220 V ± 10 % Dimensions (main unit): 280 × 280 × 400 mm Dimensions (ageing oven): 400 × 280 × 180 mm Weight (main unit): 6.5 kgs Weight (ageing oven): 4.5 kgs Features Digital LED screen for visual monitoring of data. Traceable operation. Constant temperature and pressure maintenance. Built-in diagnostics. Dual parallel clamps fixtures. Anti-corrosive structural unit.
