Tetra Pak, Tetra Top 170 V, 2003, 9000 Cartons/h, 1000ml/750ml/500ml, Non-Aseptic

Tetra Pak, Tetra Top 170 V, 2003, 9000 Cartons/h, 1000ml/750ml/500ml, Non-Aseptic

Description

  1. Overview
    1. Machine type: Tetra Pak Tetra Top 170 V filling plant
    2. Manufacturer: Tetra Pak
    3. Model: Tetra Top 170 V
    4. Year of construction: 2003
    5. Non-aseptic Tetra Top 170 V filling line
    6. As this is non-aseptic, it cannot be used for long-life milk products, etc.
    7. Availability: Immediately
  2. Specifications
    1. Volume: 1,000 ml, 750 ml, 500 ml
    2. Tray type: Tetra Top flat top
    3. Capacity: 9,000 cartons per hour
    4. Rated power of the engine: 9,000 eh per hour
    5. Formats: 1,000 ml cartons, 750 ml cartons and 500 ml cartons
    6. Filling machine Tetra Top 170 V, starting 2004, 2003 contract
    7. Aseptic: False
  3. Condition
    1. Condition: Good (used)
    2. Operating hours: 13,772 h
    3. Mileage (31.08.2011): 13,772 operating hours
    4. Warranty: No warranty
    5. Operability: Disconnected/removed. Cannot be displayed in operation
    6. The line was dismantled by Tetra Pak at the end of November 2011
  4. Included Equipment
    1. 1 x HSE for conveying
    2. 1 x granulate funnel
    3. 1 x HCCU for foam cleaning
    4. 1 x on stainless steel cylinder converted volume adjustment 190 V type
    5. 1 x 20 replacement cartridges
    6. 2 x screw machines Tetra Pak type capper 20 to screw on 38 mm screw caps
    7. 1 x manual roll feed to insert the rollers in the ASU
    8. 1 x roll pallet truck to the roller conveyor
    9. 1 x retrofit Rittal air conditioning unit for control cabinet
    10. 1 traypacker make Sema, formats Tetra Top 1,000 ml, 500 ml wrap around, tray 2 x 5 (performance with 2 x 5 Tetra Top 9,000 cartons per hour); can be changed on Tetra Slim 1,000 ml tray 2 x 6 (performance at Slim 6,600 cartons per hour)
    11. 1 package of spare parts available
    12. 1 spare parts package Sema packer available
  5. Location and Transport
    1. Transport systems are not included and must be purchased separately by Tetra Pak or another manufacturer
