NovaStar, CG212, Hot Melt Coating Machine, Working Width 1575mm, 0.05-0.23mm Thickness, 0.5-3 m/min (New)

Description

  1. Overview
    1. Width: 1600 mm
    2. Working width: 1575 mm
    3. For light gauge aluminum foil
    4. Purpose: to apply hard shell wax (water-based emulsified wax) to both sides of aluminum sheets in one pass
  2. Specifications
    1. Metal thickness range: 0.002” to 0.009” (0.0508 to 0.2286 mm)
    2. Wax application amount: 7 to 12 mg per square foot (75 to 130 milligrams per square meter)
    3. Wax consistency: similar to milk
    4. Wax melting point: less than 220°F (104°C)
    5. Adjustable coating speed: 0.5 to 3 meters per minute
  3. Weight
    1. Net weight / gross weight: 2000 kg
