Cooling: cylinder cooling fresh water, charge-air cooler (two-stage) fresh water, fuel injector cooling fresh water (only when running on HFO)
Starting method: compressed air
Generator Specifications
Frequency: 50 Hz
Voltage: 11 kV
Output approx.: 10.940 kVA
Alternator efficiency: 97.24%
Continuous power output: 8.752 kWel
Specific fuel consumption at 100% load: 190.35 g/kWel
Lube oil consumption (+ 20% tolerance): 4.5 kg/h
Weight per unit: 151 ton
Parameters according to ISO condition
Condition and Maintenance
The generator set is highest quality and must be overhauled after 45,000 working hours
Included and Optional Services
Transport: transport of the generator sets to the destination can be organized and arranged at the customer's request
Engineering: planning of the power plant site, buildings as well as infrastructure and grid connection can be organized and arranged at the customer's request
Construction services: construction services and site management of the buildings and infrastructure can be organized and arranged at the customer's request
Power plant: construction, erection and commissioning of the generators and other power plant components can be organized and arranged at the customer's request
Warranty: 1 (one) year warranty will be given if the generator sets are assembled and commissioned by a Man certified company
Location and Notes
Subject to prior sale
Technical dates and statements with reservations of error
Calculation of the approximate consumption for a power plant consisting of 4 gensets: with four engines and a maximum output of 36 MW, i.e. 360.000 kW/h, a daily running time of 12 hours per day at full load results in an output of 4.320,000 kW/h
Specifications
Weight: 151000
