Description Pulse Type And Frequency Pulsed technology Repetition frequency: 1-3000 kHz (gradient adjustable) Scanning Head And Beam Delivery Scanning range: 180 x 180 mm, continuously adjustable; dual-axis support for 8 scanning modes Standoff distance from the belt surface: 160 mm (optional 210 mm / 254 mm / 330 mm / 420 mm) Throughput And Processing Rate Estimated cleaning speed: 20000 mm/s Cooling And Environmental Requirements Cooling method: Water-cooled Environmental requirements: Temperature 5-40 °C, humidity ≤ 80% Fume Extraction And Filtration Approach to removing and filtering resin dust: External dust collector Compliance with local air quality regulations or recommendations System Footprint And Mounting Dimensions (L x W x H): 770 mm x 375 mm x 800 mm / 30.3 in x 14.8 in x 31.5 in Installation type: Stand-alone cabinet Automation And Controls PLC user interface Electrical Requirements Supply voltage: 220 V ± 5%, 50 Hz, maximum power consumption: 2 kW No special requirements Safety Features And Certifications Class IV CE, ISO 9001, FDA, TÜV Maintenance And Service Expected consumables or maintenance intervals (e.g., optics cleaning/replacement) Availability of spare parts, local service support, and training Estimated Lead Time And Shipment Lead time: 15 days, shipment: 35-40 days by sea, installation and commissioning support: 2 days Condition And Testing Tested on a textile machine's conveyor belt with good result Result may differ from your working conditions
