Description Overview Siemens SGT 800 gas turbine Power generation: 45.3 – 62.5 MW(e) Combines a simple, robust design for high reliability and easy maintenance with high efficiency and low emissions. Designed for flexible operation, making it perfectly suited for peaking power and grid support. Technical Data Gross power output: 45.3 ~ 62.5 MW(e) Fuel: natural gas, liquid fuel, dual fuel (natural gas, other gases within specification, liquid fuel (diesel no. 2) and dual fuel (gas and liquid)) Frequency: 50 / 60 Hz Gross heat rate: 8,759 ~ 9,381 kJ/kWh Turbine speed: 6,600 rpm NOₓ emissions: 15 ~ 25 ppmvd (NOx emissions at 15% O₂ on fuel gas with DLE) Dimensions (L x W x H): 21 x 7.5 x 6.6 m / 285,000 kg Key Features SGT-800 core engine is available with different ratings. Robust dual-fuel DLE system for low environmental footprint. Excellent fuel flexibility allows for high content of inert gases, hydrogen and heavy hydrocarbons in the gas fuel composition. SGT-800 classic package – consists of preassembled modules for easy transportation and installation at site. SGT-800 single lift package – small footprint and short installation and commissioning time at site; including 48h core engine exchange capability. Performance Data Power output: 45 MW / 45.3 MW(e) Fuel: natural gas; dual fuel (gas/liquid) Frequency: 50/60 Hz Gross efficiency: 38.4% Heat rate: 9,381 kJ/kWh (8,892 BTU/kWh) Turbine speed: 6,600 rpm Pressure ratio: 18.3: 1 Exhaust mass flow: 115.1 kg/s (253.7 lb/s) Exhaust temperature: 574 °C (1,065 °F) NOₓ emissions: ≤ 15 ppmvd Physical Dimensions (Classic Package) Approximate weight: 285,000 kg (628,300 lb) Length: 20.8 m (68 ft) Width: 7.3 m (24 ft) Height: 6.6 m (22 ft)
