Description Overview Total weight: 8,440 kg (universal); 10,315 kg (jumbo) Belt speed: 0 to 800 meters per minute Fabric drawing off speed: 70 meters per minute Utility Connections Water inlets: 1 1/2 inch gas Water max. pressure: 2 bar Steam inlet: 2 inch gas Steam max. pressure: 5 bar Compressed air inlet: 1/2 inch gas Compressed air max. pressure: 8 bar Electrical Specifications Feed voltage: 380 volts, 50 Hz Feed voltage of control panel: 24 volts a.c., 50 Hz Total installed power: 85 kW per machine with squeezer Main D.C. Motor for Belt Drive Speed: 2225 rpm Armature voltage: 400 volts, servoventilated Power: 26.9 kW Centrifugal Fan Motor for Air Circulation Speed: 2950 rpm Power: 30 kW A.C. Reduction Gear Reel Drive Speed: 1400 rpm Power: 0.75 kW A.C. Squeezer Roller Motor Speed: 1450 rpm Power: 11 kW
