Description Overview Foam tensile and tear tester Used to test material tensile, tear, and elongation ability, such as sponge, foam, and other porous elastic materials Software can issue report with results for maximum force, elongation, tensile strength, peel strength, tear strength, compression strength, etc. Features Motor system: Panasonic servo motor and servo driver and high precision ball screw Can save results automatically after test is finished and it is manual filing Software language: English Display method: PC and LCD Main Technical Parameters Maximum force: 200 kg (2 kN) Load cell: Germany brand load cell for high accuracy Control system: LCD / PC with Windows 7 system Motor: Panasonic servo motor with DC variable speed drive system, high-precision mechanical ball screw rod Force reading: kgf, Ibf, N, kN, T, etc. Stroke: 900 mm including fixture Load cell resolution: 1/250,000 Load precision: ≤0.5% Test speed: 0.1 ~ 500 mm/minute (adjustable) Curves display: load-elongation, elongation-time, time-elongation, stress-strain Data display: maximum force, speed, sample information, strength (kPa, MPa, N/mm, N/mm²) etc. Safety Features E-stop, over-load protection, upper and lower limit switches, load sensor with automatic retreat Design Standard ASTM D test E and test F
