NovaStar, NN452, Meltblown Non-Woven Production Line, 1600mm Width, 1.5 to 2.0 T/24h Capacity (New)

NovaStar, NN452, Meltblown Non-Woven Production Line, 1600mm Width, 1.5 to 2.0 T/24h Capacity

Description

  1. Equipment Introduction
    1. Process introduction of melt spray non-woven cloth production line: melt jet nonwovens process uses high-speed hot air to draft the thin flow of polymer melt extruded from the nozzle hole of die head.
    2. From this form the ultrafine fiber and condense in the coagulation screen or roller and rely on their own bonding and become nonwoven.
    3. Process standard flow: polymer preparation → melt extrusion → metering pump → melt jet die assembly → melt trickle stretching → cooling → receiving device.
  2. Product Requirements
    1. Effective width: 1600 mm.
    2. Maximum coil diameter: 1200 mm.
    3. Yield: 1.5 to 2.0 t per 24 hours (20 gsm).
    4. Filament size: 2 μm to 5 μm.
    5. Main raw materials: polypropylene slicing (melting and spraying special materials).
    6. Product weight: 15 to 200 gsm.
    7. Mechanical speed: 10 to 80 meters per minute.
    8. Installed capacity: 450 kW.
    9. Equipment dimensions: 16000 mm × 6000 mm × 6000 mm.
  3. Extruder
    1. One extruder.
    2. Feeding platform: a set including vacuum automatic feeding system, hopper cone storage type, hopper capacity 200 liters.
    3. Drive motor: DC motor (Dongyuan), driving power 160 kW, speed regulator.
    4. Reducer: one, type of special gear box for plastic machinery, gear material is 20GrMoTi high quality alloy steel.
    5. Cylinder: diameter 90 mm, material of 38CrMoAl high quality alloy steel treated by ion nitriding surface hardening, nitriding depth 0.5 to 0.8 mm, surface hardness HV 850 to 1100, heating mode electric heater, temperature control PID intelligent temperature control instrument automatic control, length-diameter ratio 33:1.
  4. Hydraulic Network Change System
    1. One set of hydraulic network change system: double-station plunger-type hydraulic quick-change network.
    2. Oil pump driven AC motor, oil pump driving power 2.2 kW.
    3. Heating mode: stainless steel electric heating.
    4. One set of pressure sensors.
  5. Melt Metering Pump
    1. One set of melt metering pump: melt pump model 90ACC.
    2. Drive motor: 3 kW.
    3. Control form: frequency conversion control.
    4. One set of pressure closed loop systems.
  6. Coat Hanger Type Melt Spray Extrusion Mould
    1. One set of coat hanger type melt spray extrusion mould (domestic brand).
    2. Formwork materials: alloyed steel and tempered.
    3. Runner surface: hard chrome plated and polished, outer surface chrome plated.
    4. Heating mode: incorporates heating tube in the mold, internal bar heating.
    5. Product width: 1600 mm.
    6. Heating zone: 9.
    7. Total heating power: 35 kW.
    8. One set of pressure sensors for die front.
  7. Melting and Spraying Spinneret
    1. One set of melting and spraying spinneret: made of precision high temperature resistant steel, each kit includes aluminum washer, distribution plate, multi-layer stainless steel mesh.
    2. Length-diameter ratio: 10 to 12:1.
  8. Air Heating System
    1. One air heating system: heating tank made of stainless steel, tank body provided with a baffle plate and an insulation layer.
    2. Heating tank inlet and outlet diameter: DN200, flange material for stainless steel.
    3. Heated medium: air.
    4. Heating power: about 180 kW.
    5. Maximum designed heating temperature: 400 °C.
    6. Service temperature: 200-350 °C (adjustable).
    7. Temperature control mode: intelligent PID automatic control.
  9. High-Pressure Fan
    1. One set of high-pressure fan: control power 45 kW.
    2. Control form: AC frequency conversion control.
    3. One set of air supply pipes.
  10. Network System
    1. One set of network system: adjustable tuyere can better solve the problem of airflow interference to the cloth.
    2. Net curtain: two copies.
    3. Conveyor belt width: 1900 mm.
    4. Net curtain material: 60 mesh stainless steel net.
    5. Two negative pressure fans.
  11. Static Poles
    1. One set of static poles: input voltage 220 volts.
    2. Maximum output voltage: 60 kV.
    3. Processing width: 1800 mm.
  12. Coiler
    1. One set of coiler: one friction roller (steel roller), roller length 2000 mm.
    2. Steel roll surface treatment: gluing and polishing.
    3. Control power: 5.5 kW.
    4. Control form: frequency conversion control.
  13. Electrical Control System
    1. PLC control, inverter synchronous control.
    2. Main motor: Siemens or Wannan motor.
    3. Main low-voltage electrical appliances: Schneider brand.
    4. Temperature control instrument: Omron or RKC.
