NovaStar, SG261, Heavy Duty Granulators, 15kW to 45kW, 960kg to 3230kg (New)

Name: NovaStar, SG261, Heavy Duty Granulators, 15kW to 45kW, 960kg to 3230kg
Brand: NovaStar
SKU: YY-1201

‹ Go Back Next Product ›

Description

Overview
1. The ape-c Series granulators are heavy duty, high speed precision granulation machines designed for the rapid size reduction of various types of material in a single pass.
Model
1. Ape-c660
Dimensions
1. Overall dimension: 1483 x 1328 x 1740 mm
2. Cutting chamber: 634 x 437 mm
3. Height of discharge port: 1567 mm
Rotor Specifications
1. Rotor diameter: 260 mm
2. Main shaft speed: 584 mm
3. Rotor knives: 3 x 2 pieces
4. Stator knives: 2 x 2 pieces
Screen and Motor
1. Screen mesh: 8 mm
2. Main motor power: 15 kW
Weight
1. 960 kg

Additional Specifications

HS code	8477.80

Specifications

Models Available

[{'model': 'APE-C660', 'weight_kg': 960, 'dimensions': '1483x1328x1740 mm', 'motor_power': '15KW', 'rotor_diameter': '260 mm', 'cutting_chamber': '634x437 mm'}, {'model': 'APE-C280', 'weight_kg': 1730, 'dimensions': '1586x1568x1814 mm', 'motor_power': '22KW', 'rotor_diameter': '320 mm', 'cutting_chamber': '834x475 mm'}, {'model': 'APE-C480', 'weight_kg': 2800, 'dimensions': '1770x1642x2425 mm', 'motor_power': '37KW', 'rotor_diameter': '420 mm', 'cutting_chamber': '834x540 mm'}, {'model': 'APE-C2100', 'weight_kg': 3230, 'dimensions': '1770x1842x2425 mm', 'motor_power': '45KW', 'rotor_diameter': '420 mm', 'cutting_chamber': '1034x540 mm'}]
