Continuous and stable ultra-high pressure can greatly improve the cutting speed on the premise of ensuring the cutting quality
It has omnidirectional safety protection devices such as pressure detection, limit alarm and automatic protection
High-power motor cooperates with cooling oil pump and automatic variable displacement oil pump
The unique design inside the oil pipeline makes the cylinder flexible in reversing direction, less resistance and low noise
Advanced pressure auto-regulating pump can ensure the pressure of low-pressure water intake to remain stable
The use of precise water filters makes the water used for cutting more pure and prolongs the use time of the components of the high-pressure system greatly
Cnc Control System
Size: 750mm x 600mm x 1600mm
Weight: 120kgs
Plc: mitsubishi, japan
Cnc control system: ncstudio v10
Program software: cnc weihong
Electrical element: siemens element
Weak electric machine: omron, japan
Servo driver: weihong
The general auto cad drawing software is skillfully combined with the automatic programming software, which can generate the nc program of cnc control system response conveniently and quickly
Special communication transmission software and usb to realize fast and bidirectional transmission between pc and cnc
The new cnc numerical control system can make the feeding speed of arc cutting 0-15m/min; the system has the function of self-inspection, support and diagnosis, and is more convenient for maintenance
Cnc numerical control system, with larger memory and more stored processing programs, can greatly reduce processing assistance time
Independently developed international advanced water jet automatic typesetting cad/cam software
It can be compatible with many international graphic design software formats, such as asc, igs, dxf, dwg, etc
Independent power supply to key components such as driver, cnc and plc provides independent anti-interference power supply, which can avoid inexplicable shutdown events and improve the integrity and accuracy of parts processing
The software of nc system is based on win7 system, which gives full play to the powerful advantages of real man-machine conversation and multi-task function; the operator can do other work such as drawing at the same time when the machine is working
Cnc system software can make installation package (software installation work) according to the current parameters of the machine at any time; users can install cnc system software at any time; without modifying any parameters, the machine can work normally and effectively improve the maintenance and reliability of the system
Sand Supply System
Working pressure: 0.2 mpa
Size: 700φ x 950
Pressure feeding system uses 0.2 mpa compressed air to push abrasives in pressure vessel intermittently through hoses to the annular sand tank on the worktable; the sand flow is automatically distributed according to the needs of cutting; the gas flow rate is small, the velocity of sand flow is slow, the wear rate is very small, and the failure rate is close to zero
The automatic sand feeder can use air pressure to send the sand placed in the barrel 5 meters away to the mini-bucket automatically, and stop automatically when it is full; if it is not enough, it will automatically replenish and work reliably and stably
100-liter automatic sand feeder, which can hold 150 kg of sand, is stable and durable; it has automatic alarm function without sand; it indicates that sand feeding can be used by up to two water jet heads
Included Components
Full sets of waterjet cutting machine: cutting table, high pressure pump, cnc control system, sand supply system, water cooling system
Spare parts: sand tube & gem
Spare parts: sand pipe jacket
Spare parts: sealing components
Spare parts: sand chamber
Spare parts: valve repair kits
Spare parts: high pressure short pipe
Spare parts: rotary connector
Spare parts: sand body
Spare parts: high pressure washer wheel
Spare parts: high pressure water switch body
Spare parts: high pressure connecting pipe
