YY-2157 TUBULAR HEAT SETTING MACHINE, WORKING WIDTH 1600mm (SINGLE), 1200 X 2 (DOUBLE)

REFERENCE NUMBER: YY-2157 TUBULAR HEAT SETTING MACHINE, WORKING WIDTH 1600mm (SINGLE), 1200 X 2 (DOUBLE) DETAILS: MAIN PARAMETER AND REQUIREMENTS: HEATING METHODS OF CHAMBER: 1. ELECTRICITY. 2. RECYCLE OIL. 3. DIRECTLY HEAT BY GAS. 4. INDIRECTLY HEAT BY GAS. INTRODUCTION: 1. HEAT SETTING MACHINE IS USED FOR PROCESSING OF TUBULAR KNITTED FABRIC. THE MACHINE MAKES SYNTHETIC AND MIXED FABRIC TO OBTAIN STABLE SIZE WITH STAINLESS STEEL ROLLER. 2. THE FABRIC IS HEATED IN THE HEATING CHAMBER AND GET COOL PROCESS WHEN FABRIC EXITING FROM MACHINE. 3. WE CAN OFFER MACHINE WITH SINGLE PASS OR DOUBLE PASS. THE HEAT SOURCE FOR MACHINE IS: ELECTRICITY, THERMAL OIL, NATURAL GAS, STEAM. *THE MACHINE CAN NOT BE USED TO PROCESS PURE COTTON FABRIC. TECHNICAL SPECIFICATION: NAME: TUBULAR HEAT SETTING MACHINE SUITABLE FABRIC: TUBULAR CHEMICAL KNITTED FABRIC WORKING WIDTH: 1600mm (SINGLE), 1200 X 2 (DOUBLE) SUPPORTING PLATE: MANUALLY REGULATE WORKING SPEED: 3 TO 20 M/MIN CHAMBER WIDTH: 2400mm POWER SUPPLY: 380V 3P 50Hz WEIGHT OF MACHINE: ≈ 4⁓5T (SINGLE), 5⁓6T (DOUBLE) DRIVE INSTALLED CAPACITY: 13KW (SINGLE), 19.94KW (DOUBLE) HEAT-SETTING TYPE: HOT AIR CIRCULATING FABRIC BREADTH CONTROL: MANUALLY REGULATE DRIVING TYPE: INDEPENDENTLY DRIVE (SINGLE), DOUBLE DRIVING (DOUBLE) TEMPERATURE CONTROL TYPE: AUTO TEMPERATURE CONTROL COMPRESSED AIR: 0.35 TO 0.6 MPA DIMENSION: 6950mm X 3300mm X 3300mm (L X W X H) SINGLE; 6950mm X 4900mm X 3300mm (L X W X H) DOUBLE; MAIN COLOR: BLUE/CUSTOMIZE
